Navicore Slim SiRF III Bluetooth GPS Receiver

Product reference: 12398

Alternative Products:

Sorry, but this product has been discontinued. However, we have selected an alternative product that may be suitable:

SiRF III Bluetooth GPS Receiver SiRF III Bluetooth GPS Receiver
In stock
£29.95

Discontinued Navicore Slim SiRF III Bluetooth GPS Receiver:

DISCONTINUED

Mobile Fun 30 Day Guarantee
Mobile Fun 1 Year Warranty
Alternatives
We have 1 alternative product available that may suit your requirements.

This product is no longer available
Delivery Options
  • Rated 4 out of 5

42 Reviews for Navicore Slim SiRF III Bluetooth GPS Receiver
Write a review

Discontinued


Featured Customer Review:

Paul
Cardiff, UK
  • Rated 5 out of 5
17th Dec 2007
Good GPS receiver
fast delivery!!! Box include everything inside. GPS is working fine. Best choice if someone want spend L30. (Navicore slim=Holux 240Slim ;) )

ButchersChoice
UK
  • Rated 5 out of 5
5th Jun 2007
A fantastic, easy to use Bluetooth GPS receiver
Firstly, Mobile Fun delivered as promised - next working day which I was very pleased with, so thanks MF. Everything was present in the box: Navicore GPS receiver, USB cable, Car adaptor, software CD and neck lanyard. Straight out of the box I turned on the GPS receiver and the display illuminated the Bluetooth and GPS symbols. Pairing the Navicore with my Sony Ericsson K800i took 20 seconds (I guessed the 0000 pairing code) and armed with software from Nav4all.com, I was away! I had no need to use the CD, I believe there is some software on there as well as the manuals though. The Navicore is the size of a pack of Wrigleys Spearmint gum and locked onto a signal within a couple of minutes of being outside of the building. Battery life is quoted at being >8 hours, but even if it's less than that I've got the charger so it shouldn't be a problem. Compared to a TomTom 700, the Navicore+Nav4All setup is a lot less friendly to use but at a fraction of the price deserves consideration. Overall, I'd recommend it if you want simple Sat Nav.

42 Reviews for Navicore Slim SiRF III Bluetooth GPS Receiver

Description of the discontinued Navicore Slim SiRF III Bluetooth GPS Receiver:

The Navicore Slim SiRF III Bluetooth GPS receiver is a fully integrated GPS receiver. It includes a rechargeable Lithium-Ion battery, GPS antenna, and Bluetooth connectivity. It also incorporates a third-generation chipset designed by America's SiRF III Technology for low power consumption. All features are fully integrated into one unit to meet the rigorous demands of consumer's professional and personal needs. Navicore Slim is a dual-function GPS receiver. Not only does it transmit satellite data through a PDA or notebook with Bluetooth interface, but it is also a traditional GPS receiver that can deliver a satellite signal through a data cable to a device without Bluetooth interface.

The compact, stylish and handy Navicore Slim is easy to carry and can be worn across the chest. This device meets a range of needs such as car navigation, security, mapping, surveying, and agricultural applications. It communicates with other electronic utilities via Bluetooth, USB-compliant interface, and has a built-in rechargeable battery to save such satellite data as the status of a satellite signal, the last location, and date and time of previous use.

With low power consumption, Navicore Slim tracks 20 satellites at a time *, re-acquires the satellite signal every tenth of a second and updates position data once a second. The power saving mode (Trickle-Power) allows the unit to operate at a fraction of the power. It also provides a time and position fix function (Push-to-Fix) that will switch on the unit at a designated time, even when the receiver stays off.

Navicore Slim SiRF III Bluetooth GPS receiver

Specification:

  • Tracks up to 20 satellites.*
  • Receiver: L1, C/A code.
  • Update rate: 1 HZ (max).
  • Antenna Type: Built in Patch Antenna.
  • Minimum signal tracked: -159dBm. *
  • Dimensions: 64 x 22 x 15 mm.
  • Weight : < 35g.
  • On/off switch: slide switcher.
  • 900 mAh Lithium-ion battery lasts for more than 8 hours of use.
  • Operation Temperature: -10 0C to + 60 0C.
  • Store Temperature: -20 0C to + 70 0C.
  • Operation Humidity:5% to 95% No condensing.
  • 3 Led Function: Bluetooth, navigation update and battery / charger status indication.
  • Position accuracy - Non DGPS (Differential GPS): Position : 5 - 25 m CEP without SA.
  • Velocity : 0.1m / sec. Time : 1 μsec sync GPS time.
  • EGNOS / WAAS / Beacon: Position :< 2.2 m, horizontal 95 % of time < 5 m, vertical 95 % of time.
  • Reacquisition: 0.1sec. Cold start: < 42 seconds. Warm start: < 38 seconds . Hot start: < 1 seconds.

*: SiRF's original chipset spec.

Navicore Slim SiRF III Bluetooth GPS receiver

Interface:

  • Output terminal: Mini-USB (DATA I/O CMOS Level)
  • NMEA protocol output : V 2.2
  • Baud Rate: 38400 bps
  • Data bit: 8
  • Parity: N
  • Stop bit: 1
  • Output Format: Standard : GGA(1),GSA(5),GSV(5), RMC(1),VTG(1). Optional : GLL, SiRF Binary
  • Compatible Bluetooth device with Serial Port Profile (SPP) Bluetooth™ version 1.2 compliant
  • Bluetooth Class 2 operation (up to 3 meter range)
  • Frequency : 2.400 to 2.480 GHz
  • Modulation: FHSS / GFSK
  • RF channels: 79
  • Input sensitivity: -80dBm
  • Output level: 4dBm
Sim Free Mobile Phone - Nokia N90What's in the box?
  • Navicore Slim SiRF III Bluetooth GPS receiver
  • Car charger
  • Quick-start guide
Bluetooth GPS ReceiverSupport
Pairing Guide for TomTom Navigator 5
Pairing Guide for TomTom Navigator 5 (Windows Mobile 5)
Pairing Guide for Navicore Personal
