How to share your 3G Mobile Broadband Connection

Sunday, October 4th, 2009

Mobile Broadband is becoming incredibly popular, but it’s not just people that are out and about all day that are finding a use for it – people who can’t get broadband through their phone line, students in halls, those in short term rental.. the list goes on.

Although the prices for mobile broadband have come down considerably over the last couple of years, if you have several people & devices that want to use the internet at the same time, getting a mobile broadband connection for everyone can prove to be quite expensive.

Thankfully though, technology has moved on and we’re no longer restricted to having to use a separate dongle for each computer we want to use and Netgear and Option have both introduced new wireless routers that will make sharing your mobile broadband connection quick and easy.

Netgear 3G Wireless Router MBR624GU

Netgear are well known for making simple, affordable wireless routers that are easy to set up, and this one is no exception. It looks similar to most of their other routers, but the big difference is that instead of having a connection to your cable modem or BT phone line, it has a USB port that you can plug just about any 3G USB Modem in to.

Netgear 3G Wireless Router MBR624GU

The router will then establish a connection to your Mobile Network, and once it’s connected it will share the internet connection over both a wireless and wired network.

By creating a wireless network it means that devices like the iPod touch, Playstation3 and eBook readers can all access the internet easily. Infact, it’s not just wireless devices that can use it. The router has 4 ethernet ports on the back that can be used to add non-wireless computers, games consoles, printers and network storage (NAS) devices to the network.

The router has all the standard security options you’d expect to find on any Netgear router and creating your secure wireless network is quick and painless. As your download amount is limited I’d strongly recommend setting up a password for your wireless network. If you don’t and your neighbours start using it, you could end up with excessive bills.

Option GlobeSurfer X1

The GlobeSurfer X1 is similar in many ways to the Netgear, but is much smaller.  It supports all 3G broadband dongles on all networks and can be up and running in a matter of minutes. Like the Netgear router, the X1 can be used to create a wired or wireless network, regardless of whether a 3G dongle is present or not.

Option GlobeSurfer X1

There are a couple of technical differences between the two routers too. Firstly, the GlobeSurfer X1 supports 802.11 b, g and n, where as the Netgear only supports 802.11g. To be honest, this shouldn’t make too much of a difference when accessing the internet, but if all your connected devices support 802.11n, it’ll make sharing files between them a fair bit quicker. Your Mobile Broadband dongle will have a limit so I’d strongly recommend setting up a password for your wireless network. If you don’t and your neighbours start using it, you could end up with excessive bills.

The other difference is to do with the ports on the back. The X1 only has 2 ethernet ports instead of 4 and has a USB port that you can use to attach USB printers or Network Storage devices as the X1 doubles up as a File and Printer server.

Points to note

It’s worth mentioning that you don’t have to have the Mobile Broadband dongle connected to either of the routers in order for your wireless (or wired) network to work.  By that I mean that even if you remove the dongle from the router, all of the devices that are connected to the network will still be connected and therefore able to access shared files, print to a networked printer or stream content from one device to another.

If you are going to be sharing your Mobile Broadband connection, you need to make sure that everyone using it is aware of the download limit that you have with your dongle. Unlike most fixed line broadband services, you don’t get unlimited downloads, with most networks capping your data at 1, 3, 5 or 15GB a month with extremely high charges if you go over your limit. If you are going to be watching video online, downloading movies or game demo’s on your games console, you’ll need to keep a close eye on how much data you’ve used. You can normally do this through the ‘My Account’ section of your service providers website.

(1 votes, average: 5.00 out of 5)

 Loading ...

Improving your Mobile Broadband signal in the car

Friday, August 28th, 2009

If you use mobile broadband while you’re travelling or you spend most of the day working out of your car, you might struggle to maintain a decent connection to your network – this will be due to the fact you’re sat in a metal box with no end of interference from all the wiring and electrical gadgets in the car.

If you’re in a cafe or at home you can boost your signal by using a Clip Antenna or a High Gain Antenna, but inside a car they won’t be anywhere near as effective. For this reason we’ve just released our 3G Mobile Broadband Vehicle Antenna for use in cars, lorries, caravans, motorhomes, boats etc.

Car Antenna for Huawei USB Modems

Unlike the Clip Antenna and High Gain antennas that sit next to you, the Mobile Broadband Vehicle Antenna is designed to be mounted on the outside of your vehicle. This way it can pick up the signal from your network and carry it directly to the antenna to provide you with a better reception and faster download speeds.

The antenna is small and portable and can be stored in the glove box or a door pocket when not in use. It measures just 15cm long and has a small magnetic base that is just over 3cm in diameter. It can be mounted in seconds and won’t cause any damage to the paintwork on your vehicle.

The Mobile Broadband Vehicle Antenna is currently only available for Huawei dongles that use the CRC9 connection.  These dongles include the E156G, E160, E160G, E169, E620 & E110.

(No Ratings Yet)

 Loading ...

Mobile Broadband Antenna range extended

Friday, August 28th, 2009

A few months ago we launched a range of Mobile Broadband Antennas that connect to your Mobile Broadband Dongle to help increase signal strength and download speeds. Up until now there have only been two options available – a Clip Antenna and a High Gain Antenna. Well, we now have a third option – a Mobile Broadband Panel Antenna – a very high gain antenna that is perfect for areas of low reception.

To give you a better understanding of each of the antennas and to help you determine which type will suit you best here’s a quick summary of all their features.

USB Modem Clip Antenna

This an ultra portable aerial that clips onto the top of your laptop screen and connects to your dongle. It has an Omni Directional aerial and will pick up signals from all directions. The Clip Antenna will improve your 3G and GPRS signal by up to 2dBi.

Clip Antenna for USB Modems

There is a Clip Antenna for just about every USB modem or Datacard, with most current USB Modem using one of the following connections:

• Clip Antenna – CRC9
• Clip Antenna – Universal

USB Modem High Gain Antenna

This is a much more powerful signal booster than the Clip Antenna and is ideal for people who have real problems with 3G reception. They are directional so you will need to point this towards your network’s transmitter in order for it to improve the signal. The High Gain antenna when positioned correctly will make a difference of up to 9dBi on a 3G network, but will not improve a GPRS Signal.

High Gain Antenna for USB Modems

These antennas include a desk stand, but can also be mounted on an internal wall for a more permanent solution. You get 1.2 metres of cable included, but this can be extended using either a 3m extension cable or a 5m extension cable.

High Gain Antennas are the best option if you have low signal levels or live on the fringe of network coverage and don’t want to be able to mount the Antenna outside.

There is a High Gain Antenna available for most of the current USB Modems with the following connections:

• High Gain Antenna – CRC9
• High Gain Antenna – Universal

Mobile Broadband Panel Antenna

Visually, the Panel Antenna looks the same as the High Gain Antenna, but there are a number of significant differences – the main one being that the Panel Antenna is weatherproof and is suitable for use outside. Concrete, Steel and thick brick walls can reduce your signal strength, so by fixing the antenna to an outside wall or mast, the antenna picks up a stronger signal than it would inside and carries it along a lossless cable through to your mobile broadband dongle.

Mobile Broadband Panel Antenna

The Mobile Broadband Panel Antenna is the best option for areas where there is good reception outside but little or variable signal inside buildings or if you are on the fringe of the network coverage. This antenna can improve signal strength by up to 11dBi on a 3G network and up to 9dBi on a GPRS network.

Mobile Broadband Panel Antennas are directional so they will need to point in the direction of your nearest network transmitter in order for them to function properly. They come with 5m of cable and a wall/mast mounting bracket.

Panel Antennas are available for most of the current USB Modems with the following connections:

• Mobile Broadband Panel Antenna – CRC9 Connection
• Mobile Broadband Panel Antenna – Universal Connection

To find out which type of connector your Mobile Broadband Dongle needs take a look at our Mobile Broadband Antenna Compatibility List.

(No Ratings Yet)

 Loading ...

How to Measure & Improve Mobile Broadband Reception

Monday, June 22nd, 2009

Note: This post is part of a series of posts about improving reception for Mobile Broadband dongles.

You may be interested in the other posts in the series:

• How to Boost your Mobile Broadband 3G Signal
• How to fit your Mobile Broadband Aerial
• Which 3G Antenna do I need?

The Problem with Mobile Broadband

Mobile Broadband has really taken off in the past 12 months – and USB Mobile Broadband dongles are now aggressively promoted by all UK mobile networks (3, Vodafone, t-mobile, Orange & O2) as a viable alternative to traditional fixed-line broadband.

However, we’ve heard from our customers that some of them are far from happy with the quality, reception and signal strength of their Mobile Broadband dongles.  But the mobile networks continue to promote Mobile Broadband as if coverage is not an issue.  Last year, the ASA even went as far as reprimanding a mobile network for some misleading advertising claims.

At Mobile Fun, we’re not entirely convinced that the quality issues surrounding mobile broadband have been fully addressed.  Okay, so UK mobile networks are investing heavily in network infrastructure, but we don’t believe that customers are getting adequate coverage, signal strength, or reliability with their Mobile Broadband dongles.

(more…)

(2 votes, average: 4.50 out of 5)

 Loading ...

How to fit your Mobile Broadband Aerial

Monday, June 15th, 2009

You’ve probably already seen on our previous post, that the best way to improve the signal to your 3G Mobile Broadband Dongle is to attach an external aerial.

Although this may sound like a complicated procedure, it really isn’t!

There are two main types of aerial, one with a dongle specific connector, and a universal one. The steps below will show you how to connect the Clip Aerial and High Gain Aerials to your dongle.

Universal Aerials

Clip Aerial:

The Clip Aerial clips on to the top of your laptop screen and is attached to the antenna pad by joining the two cables together. It’s a simple screw connection so shouldn’t cause you any hassle.

To connect the aerial to your dongle, you just need to sit the antenna pad on top of your dongle, and then securing by wrapping the velcro strap around it.

That’s it – just plug the dongle into your laptop and you should see a difference in signal straight away.

High Gain Aerial:

The High Gain is Aerial designed to be a more permanent solution, and as a result. installation for this aerial is slightly different as the aerial needs to point in the direction of your nearest transmitter.

The 1.2 metre cable that is included will need to be connected to both the aerial and the antenna pad. As with the clip aerial, its a simple screw connection to attach them, and it’s not possible to connect them the wrong way round. If you need a longer cable, 3 metre and 5 metre extension cables are available (High Gain Aerial only).

To connect the aerial to your dongle, you just need to sit the antenna pad on top of your dongle, and then securing by wrapping the velcro strap around it.

You can now plug your dongle in and launch the broadband control panel. You just need to position the aerial so that it now points towards your nearest network transmitter. If you don’t know where it is, then just rotate the aerial until the signal strength increases.

Dongle Specific Aerials

Clip Aerial:

The Clip Aerial clips on to the top of your laptop screen and is attached to the antenna pad by joining the two cables together. It’s a simple screw connection so shouldn’t cause you any hassle.

To connect the aerial to your dongle, you need to locate the antenna connection – this is normally hidden under a dust flap. Once you’ve found it, gently push the aerial connector in as far as you can.

That’s it – just plug the dongle into your laptop and you should see a difference in signal straight away.

High Gain Aerial:

The High Gain Aerial is designed to be a more permanent solution, and as a result. installation for this aerial is slightly different as the aerial needs to point in the direction of your nearest transmitter.

The 1.2 metre cable that is included will need to be connected to both the aerial and the antenna pad. As with the clip aerial, its a simple screw connection to attach them, and it’s not possible to connect them the wrong way round. If you need a longer cable,3 metre and 5 metre extension cables are available (High Gain Aerial only).

To connect the aerial to your dongle, you need to locate the antenna connection – this is normally hidden under a dust flap. Once you’ve found it, gently push the aerial connector in as far as you can.

You can now plug your dongle in and launch the broadband control panel. You just need to position the aerial so that it now points towards your nearest network transmitter. If you don’t know where it is, then just rotate the aerial until the signal strength increases.

If you want help finding your nearest network transmitter, the OFCOM sitefinder website has maps showing the locations of all transmitters.

(9 votes, average: 4.11 out of 5)

 Loading ...

How to Boost your Mobile Broadband 3G Signal

Friday, March 6th, 2009

(more…)

(25 votes, average: 3.36 out of 5)

 Loading ...

Which 3G Antenna do I need?

Monday, March 2nd, 2009

The table below shows the current 3G Broadband Dongles and the Antennas that are available. If you aren’t sure which dongle you have, our post on how to boost your 3G signal will show you where to find this information.

There are now three two different types of antenna available. The standard Clip Antenna is designed to be a portable solution that clips onto the screen on your laptop or sits on your desk. It is omni-directional, which means that it will pick up signals from all directions. The High Gain 3G Directional Antenna is a more powerful signal booster. It is directional, which means that you will need to point this towards your networks transmitter in order for it to improve the signal. The High Gain antenna when positioned correctly will make a significant difference to the signal you receive, and can be wall mounted as a permanent fixture. The latest dongle is the Panel Antenna. This is similar in many ways to the High Gain Antenna, but is slightly stronger and is weatherproof – making it perfect for outdoor installations.

Clip Antenna - High Gain Antenna - Panel Antenna

More information on the different antennas can be found on our blog post “Mobile Broadband Antenna Range extended”

To find your dongle quickly, press “ctrl” and “f” on your keyboard, and then type in the model number of your dongle (eg: E160G) to search this page. If your dongle is not listed here, don’t worry, this is only a snapshot of the most popular dongles.

We’ve now made it easier for you to find the right antenna for your dongle. You can now use the smart filter in the mobile broadband section of the main site. Go to the USB Dongle Antennas and select your dongle from the drop down box at the top of the page to see the antennas that are compatible with your 3G Broadband Modem.

If you still can’t find your dongle, please add a comment with the network, dongle make and model number and I’ll find out which antenna you need and add it to the list. If you have any questions about using the dongle or aren’t sure which one you need, please ask us on the Mobile Fun Forums
